Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
Datos del producto:
| Lugar de origen: | Porcelana |
| Nombre de la marca: | DOW |
| Certificación: | CE |
| Número de modelo: | IntegraTecTM XP 51/ XP 51 IG ((anteriormente conocido como SFD/SFP-2860XP) |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 pieza |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Embalaje estándar de exportación |
| Tiempo de entrega: | 5- 8 días de trabajo |
| Capacidad de la fuente: | 60000 unidades por mes |
|
Información detallada |
|||
| Modo de filtración XP 51 IG: | Presurizado | Membrana tipo IG XP 51: | Fibra hueca |
|---|---|---|---|
| Material de membrana IG XP 51: | PVDF (fluoruro de polivinilideno) | XP 51 Tamaño de poro de membrana IG: | Aprox. 0.03 µm |
| Proceso de funcionamiento del módulo: | De extremo muerto | Otros componentes del módulo humedecido: | Poliuretano, polietileno y poliamida |
| XP 51 Área de membrana activa IG: | 51 m² | XP 51 Peso de envío de IG: | 60 kg |
| XP 51 IG Peso vacío: | 48 kg | Llena de peso: | 83 kg |
| Aplicación del producto: | Tratamiento de aguas residuales | Ventajas del XP 51 IG: | adecuado para diseños de sistemas con altura o espacio limitados |
Descripción de producto
Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
The XP 51 is a compact model in the XP series, suitable for systems with limited height or space.
1. Membrane material: PVDF
2. Nominal pore size: approximately 0.03 μm
3. Effective membrane area per module: approximately 51 m²
4. Module diameter: approximately 203 mm (8 inches), length: approximately 1520 mm (60 inches)
5. Typical operating flux is similar to the SFP2860, typically in the range of 40–110 LMH
6. Primarily used in containerized water treatment systems, small industrial RO pretreatment units, and modular equipment.
7. This model's advantage lies in its flexible system integration, suitable for standardized export equipment and customized skids.
Key Features Proven XP™ hydrophilic PVDF fibers:
• Excellent stain and chlorine resistance.
• High removal of colloidal particles, bacteria and viruses.
• Excellent filter permeability.
• Easy to clean and wet.
Optimized module design: Open platform design to fit customer-built skids.
• Short module design for height-restricted or containerized installations.
• High operating recovery rate with high air scour tolerance.
• Reduced chemical consumption through maintenance cleaning protocols.
• Rugged materials for long service life.
• Easy installation and low maintenance costs.
Product Specifications
Operating Parameters
