Dupont XP77 IG PVDF Hollow Fiber Ultrafiltration Module with 77 m² Effective Membrane Area for Industrial Water Systems
Datos del producto:
| Lugar de origen: | Porcelana |
| Nombre de la marca: | Dupont |
| Certificación: | CE |
| Número de modelo: | IntegrateC ™ XP 77/XP 77 IG (anteriormente SFP/SFP 2880XP) |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 pieza |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Embalaje estándar de exportación |
| Tiempo de entrega: | 5- 8 días de trabajo |
| Capacidad de la fuente: | 60000 unidades por mes |
|
Información detallada |
|||
| Modo de filtración: | Presurizado, de afuera hacia adentro | Estructura de la membrana: | Fibra hueca |
|---|---|---|---|
| Material: | PVDF | Tamaño nominal del poro: | 00,03 μm |
| Proceso de filtración: | De extremo muerto | Longitud total: | 2360 milímetros |
Descripción de producto
Dupont XP77 IG PVDF Hollow Fiber Ultrafiltration Module for Industrial Water Systems
XP77 IG is a high-efficiency pressurized ultrafiltration membrane module engineered for demanding water treatment environments. Utilizing advanced hydrophilic PVDF hollow fiber technology, the module delivers stable filtration performance with excellent resistance to fouling and oxidants.
Its optimized structural design enables high recovery rates, reduced chemical consumption, and long operational lifespan. With a large effective filtration area of 77 m², the module significantly improves system productivity while minimizing footprint and operating costs.
Designed for open-platform integration, XP77 IG is ideal for system integrators and OEM water treatment solutions.
- Advanced hydrophilic PVDF membrane with strong anti-fouling capability
- High removal efficiency for bacteria, viruses, and colloidal particles
- Large filtration area improves throughput and system efficiency
- Excellent chlorine resistance for harsh water conditions
- Supports high air scouring intensity for better cleaning performance
- Reduced cleaning frequency and chemical usage
- Modular design suitable for skid-mounted systems
- Easy installation and low maintenance requirements
- Industrial process water treatment
- Wastewater recycling and reuse
- Municipal water filtration systems
- Pretreatment for reverse osmosis (RO) systems
- High recovery filtration applications
| Membrane area | Module volume | Weight (empty / water filled) |
||||||
| Model | Type | / | m2 | ft2 | Liters | Gallons | Kg/lbs | Kg/lbs |
| XP77 IG | Industrial | 77 | 829 | 39 | 10.3 | 61/100 | 135/220 | |
| XP 77 | NSF/ANSI 61 and 419 | 77 | 829 | 39 | 10.3 | 61/100 | 135/220 | |
| SI units | US units | |
| Filtrate Flux @ 25ºC | 40-110 l/m2/ hr | 24-65 gfd |
| Flow range | 2.0 – 8.5 m3/hr | 8.8 – 37.4 gpm |
| Temperature | 1-40ºC | 34-104ºF |
| Max. inlet module pressure (@ 20ºC) | 6.25 bar | 90.65 psi |
| Max. operating TMP | 2.1 bar | 30.5 psi |
| Max operating air scour flow | 12 nm3/hr | 7.1 scfm |
| Max backwash pressure | 2.5 bar | 36 psi |
| Operating pH | 2- 11 | |
| NaOCl (max.) | 2,000 mg/L | |
| Particle size (max.) | 300 µm | |
| Flow configuration | Outside in,dead end flow | |
| Expected filtrate turbidity | ≤0.1 NTU | |
| Expected filtrate SDI | ≤2.5 | |
| / | ||
| / | ||
