DuPont™ AmberLite™ IRC120 N Gaussian, Gel, Strong Acid Cation Exchange Resin
Datos del producto:
| Lugar de origen: | PORCELANA |
| Nombre de la marca: | Dupont |
| Certificación: | ISO9001 |
| Número de modelo: | DuPont ™ Amberlite ™ IRC120 NA |
| Documento: | IER-AmberLite-IRC120-Na-PDS...en.pdf |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 por ciento |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Embalaje de exportación estándar |
| Tiempo de entrega: | 5- 8 días de trabajo |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | 60000 unidades por mes |
|
Información detallada |
|||
| Copolímero de productos: | Estireno-divinilbenceno | Tipo de producto: | Catión ácido fuerte |
|---|---|---|---|
| Grupo funcional del producto: | Ácido sulfónico | Aplicaciones primarias del producto: | ablandamiento de aguas industriales |
| Forma física: | Cuentas esféricas translúcidas ámbar | Forma iónica (como se envía): | Na⁺ |
| Capacidad de intercambio total: | ≥ 2.0 Eq/L (forma na⁺) | Capacidad de retención de agua: | 40.0 - 50.0% (formulario NA⁺) |
Descripción de producto
1. Product Overview
DuPont™ AmberLite™ IRC120 Na is a gaussian, gel-type, strong acid cation exchange resin designed for industrial water softening applications. With a long-established track record of reliable performance, this durable resin offers an optimal balance of high capacity and mechanical strength, making it ideal for co-current regenerated systems in industrial water treatment. It is also suitable for demineralization applications where the sodium form is preferred.
2. Applications
-
Industrial water softening
-
Demineralization (when sodium-form resin is specified)
3. Compatible System Designs
-
Co-current regeneration systems
4. Historical Reference
Previously sold as AmberLite™ IR120 Na Ion Exchange Resin.
5. Typical Properties
Physical Properties
| Property | Specification |
|---|---|
| Copolymer | Styrene-divinylbenzene |
| Matrix | Gel |
| Type | Strong acid cation |
| Functional Group | Sulfonic acid |
| Physical Form | Amber translucent spherical beads |
Chemical Properties
| Property | Specification |
|---|---|
| Ionic Form (as shipped) | Na⁺ |
| Total Exchange Capacity | ≥ 2.0 eq/L (Na⁺ form) |
| Water Retention Capacity | 40.0 – 50.0% (Na⁺ form) |
Particle Size Distribution
| Parameter | Specification |
|---|---|
| < 300 μm | ≤ 2.0% |
| > 1180 μm | ≤ 4.0% |
ℹ For additional particle size information, refer to Document No. 45-D00954-en.
6. Stability & Density
-
Swelling (Na⁺ → H⁺): ≤ 11%
-
Particle Density: 1.27 g/mL
-
Shipping Weight: 817 – 840 g/L
7. Operating Conditions
-
Temperature Range (Na⁺ form): 5 – 150°C (41 – 302°F)
-
pH Range:
-
Service Cycle: 1 – 14
-
Stable: 0 – 14
-
⚠ For detailed information on minimum bed depth, operating conditions, and regeneration procedures, refer to Tech Fact Document No. 45-D01131-en.
8. Hydraulic Characteristics
-
Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
-
Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water and well-classified beds at service run start).
(Note: Refer to original document for graphical data.)
9. Safety & Compliance
-
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
-
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
