Veolia E-Cell MK-3 Mini HT EDI module for pharmaceutical ultrapure water production
Datos del producto:
| Lugar de origen: | PORCELANA |
| Nombre de la marca: | VEOLIA |
| Certificación: | CE |
| Número de modelo: | Veolia edi mk-3miniht |
| Documento: | FSpwE-CellMK-3MiniHT_EN.pdf |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 PC |
|---|---|
| Precio: | Negociable |
| Detalles de empaquetado: | Embalaje de exportación estándar |
| Tiempo de entrega: | 1 mes |
| Condiciones de pago: | T/T |
| Capacidad de la fuente: | 60000 unidades por mes |
|
Información detallada |
|||
| Rango de caudal de miniht: | 0.5–1.6 m3 /h (2.2–7.0 GPM) | Miniht Producto envío de peso: | 57 kg (126 libras) |
|---|---|---|---|
| Dimensiones de miniht de este modelo (ancho x altura x profundidad): | 30 cm x 61 cm x 29 cm | Resistividad de miniht: | ≥ 10 (farmacéutico) o ≥ 16 Mohm-CM (industrial |
| Producto sodio: | ≤ 3 PPB (industrial) | Temperatura de desinfección máxima del producto: | 85ºC (185ºF) |
| PRESIÓN DE INTERNA DE LANTIZACIÓN MÁXIMA DEL PRODUCTO: | 2.1 bar (30 psi) | aplicación del producto: | El agua purificada farmacéutica y de laboratorio que cumple con USP y EP |
| Resaltar: | Veolia E-Cell MK-3 EDI module,pharmaceutical ultrapure water EDI,mini HT EDI module |
||
Descripción de producto
The Veolia E-Cell MK-3 Mini HT Electrodeionization (EDI) Module is designed for polishing reverse osmosis (RO) permeate to produce ultra-pure water. It delivers high-purity water (up to 10 MΩ·cm resistivity, with ≤5 ppb silica) without chemical regeneration. Ideal for power generation, semiconductors, microelectronics, and pharmaceuticals, this compact module (30x61x28 cm) offers continuous operation, high recovery rates (78-93%), and hot water sanitization capabilities
| Flow Rate Range | 0.5–1.6 m³/h (2.2–7.0 gpm) |
| Shipping Weight | 57 kg (126 lbs) |
| Dimensions | 30 cm x 61 cm x 29 cm |
| Resistivity | ≥ 10 MOhm-cm (Pharmaceutical) or ≥ 16 MOhm-cm (Industrial) |
| Maximum Sanitization Temperature | 85ºC (185ºF) |
- Patented HT-EDI™ technology for reagent-grade water production
- 90% lower energy consumption compared to mixed-bed systems
- Maintenance-free operation with intelligent control system
- Real-time monitoring of conductivity, pH, and pressure drop
- Patented staggered flow channel design prevents scaling
Maintains resistivity above 18.2 MΩ*cm with 22% energy reduction compared to traditional EDI equipment. Achieves recovery rates exceeding 90% even with high-hardness raw water.
- Basic Unit - Standalone purification
- RO-EDI Integrated - Complete purification skid
- GMP Version - With full validation support
- CE, RoHS, CSA and EAC marked
- FDA-compliant materials
- UKCA certified
- Manufactured in ISO 9001 and ISO 14001 facility
- Halal certified by IFANCA®
| Parameter | Value |
|---|---|
| Inlet Pressure | 6.9 bar (100 psi) |
| Max Temperature | 40°C (104°F) |
| Pressure Drop | 1.4-2.8 bar (20-40 psi) |
| Recovery Rate | Up to 93% |
| Conductivity | <117 µS/cm |
| pH Range | 4-11 |
Ideal for water for injection, pharmaceutical purified water, and laboratory purified water systems. Complies with USP, EP, and other pharmacopeia standards.
