BWC200 Containerized BWRO System - 200 m³/day Capacity, 70% Recovery Rate, 1.56 kWh/m³ Energy Efficiency
Datos del producto:
| Lugar de origen: | Porcelana |
| Nombre de la marca: | FG Water Technologies |
| Certificación: | CE |
| Número de modelo: | BWC100 |
Pago y Envío Términos:
| Cantidad de orden mínima: | 1 |
|---|---|
| Detalles de empaquetado: | Estándar |
| Tiempo de entrega: | 30 días laborables |
| Condiciones de pago: | T/T |
|
Información detallada |
|||
| Flujo de alimentación nominal: | 14,29 m³/h | Tasa de recuperación nominal: | 70% |
|---|---|---|---|
| Potencia nominal: | 15.6kw | Consumo de energía: | 1,56 kWh/m³ |
| Cantidad de membrana RO: | 12 pcs | Tamaño del contenedor: | 20 pies |
Descripción de producto
200 m³/day Desal BWC200 – Mid‑Capacity Containerized BWRO
When your demand doubles but space is still limited, the BWC200 delivers 10 m³/h (200 m³/day) from a single 20‑ft container. It shares the compactness of the BWC100 but packs 12 RO membranes and a more powerful pump, yet consumes only 1.56 kWh/m³. Its enhanced pre‑filtration handles variable feed water, while the SS316 piping and heavy‑duty paint ensure years of trouble‑free service. The BWC200 is the go‑to choice for expanding municipalities, hotels, and light industrial plants that cannot afford downtime.
Key Specifications
| Parameter | Unit | Value |
|---|---|---|
| Rated Product Flow | m³/h | 10 |
| Rated Product Flow | L/s | 2.78 |
| Rated Recovery Rate | % | 70 |
| Rated Feed Flow | m³/h | 14.29 |
| Max System Pressure | barg | 20 |
| RO Membrane Spec | inch | 8,040 |
| RO Membrane Qty | pcs | 12 |
| Dry Weight | ton | 6 |
| Container Size | ft | 20 |
| Rated Power | kW | 15.6 |
| Energy Consumption | kWh/m³ | 1.56 |
| Installed Power | kW | 30.2 |
| Power Input | - | 3PH, 380V ±10%, 50Hz |
System Features
- Optimised energy‑to‑output - more water per watt than many competitors
- Standardised components - pumps and valves are off‑the‑shelf for quick spares
- Quiet operation - acoustic insulation makes it suitable for residential areas
- Advanced pre‑treatment - sand filter + cartridge filter protects membranes from spikes in turbidity
Ordering Information
- Standard code: BWC200 (204A003)
- Filter kit (standard): 244P003
- Insulation kit: 254P003
- Premium code: BWC200H (H204A103)
- Filter kit (premium): 244P005
- Insulation kit (premium): 254P003
Applications: Small towns, boutique hotels, food processing, car wash chains, public parks.
